Name: سوئیچ شبکه C9300X-24Y-E سیسکو
SKU: C9300X-24Y-E
Availability: OutOfStock

توضیحات

سوئیچ شبکه C9300X-24Y-E سیسکو از سری سوئیچ های 9300 سیسکو می باشد، سوئیچ‌ های سری Catalyst 9300 با قابلیت کامل جایگذاری از پاور و فن و پشتیبانی از استکینگ با پهنای باند تا 480 گیگابیت در لایه 3 ارائه شده است.

سوئیچ C9300X-24Y-E سیسکو با 24 پورت با پاور پیش فرض PWR-C1-715WAC نیز ارائه شده است.

مشخصات سوئیچ شبکه 9300X-24Y-E سیسکو

مشخصات سوئیچ سیسکو C9300X-24Y-E
General
Device Type	Switch – 24 ports – L3 – managed – stackable
Enclosure Type	Rack-mountable 1U
Subtype	25 Gigabit Ethernet
Ports	24 x 1/10/25 Gigabit SFP28
Performance	Switching capacity: 2000 Gbps Switching capacity with stacking: 3000 Gbps Forwarding rate: 1488 Mpps Forwarding rate with stacking: 2232 Mpps
Capacity	IPv4 routing table entries: 39000 Flexible NetFlow entries: 128000 Direct IPv4 routes: 24000 Indirect IPv4 routes: 15000 IPv6 routing table entries: 19500 VLAN IDs: 4094 Switched virtual interfaces (SVIs): 1000 Multicast routing flow table: 8000 QoS scale entries: 4000 ACL scale entries: 5000 PVST instances: 300 STP Virtual Ports for PVST: 13000 STP Virtual Ports for MST: 13000 Routed ports: 448
MAC Address Table Size	32000 entries
Jumbo Frame Support	9198 bytes
Routing Protocol	OSPF, IS-IS, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF
Encryption Algorithm	256-bit AES
Features	DHCP support, trunking, Syslog support, full duplex mode, Stateful switchover (SSO), Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Quality of Service (QoS), Non-Stop Routing (NSR), Remote Switch Port Analyzer (RSPAN), Management Information Base (MIB), Cisco StackWise-480 technology, Cisco StackPower technology, Flexible NetFlow (FNF), Multicast Source Discovery Protocol (MSDP), 802.1x authentication, 16MB packet buffer, FTP client, MACsec support, 3 fans, Control plane protection (CoPP), Virtual Extensible LAN (VXLAN), Application Visibility and Control (AVC), Source-Specific Multicast (SSM), integrated Wireshark, VLAN Double Tagging (Q-in-Q), Ethernet over MPLS (EoMPLS), Hierarchical Virtual Private LAN Service (H-VPLS), Private VLAN, Layer 3 VPN (L3VPN) support, Encapsulated Remote SPAN (ERSPAN), Security Group Tag (SGT) caching, Security Group Access Control List (SGACL), IT Service Management (ITSM) integration, third-party IP Address Management (IPAM) integration, Cisco StackWise-1T technology
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at
RAM	16 GB
Flash Memory	16 GB
Status Indicators	Status
Mean Time Between Failures – MTBF (hours)	249,350
Expansion / Connectivity
Interfaces	24 x 1/10/25GBase-X SFP28 ¦ 1 x USB 2.0
Expansion Slots	1 (total) / 1 (free) x expansion slot
Power
Power Device	Internal power supply
Power Provided	715 Watt
Voltage Required	AC 120/230 V (50/60 Hz)
Miscellaneous
Compliant Standards	CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, ICES-003 Class A, EN 61000-4-5, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, EN 55022 Class A, FCC CFR47 Part 15 A, EN 300 386, TVCN 7317, VCCI V-3/2009 Class A, CAN/CSA-C22.2 No. 60950-1
Dimensions & Weight
Width	17.5 in
Depth	17.6 in
Height	1.73 in
Weight	16.2 Pounds
Manufacturer Warranty
Service & Support	Limited warranty – replacement – lifetime – response time: next business day ¦ Technical support – consulting – 90 days
Environmental Parameters
Min Operating Temperature	23 °F
Max Operating Temperature	113 °F
Humidity Range Operating	5 – 90% (non-condensing)
Min Storage Temperature	-40 °F
Max Storage Temperature	158 °F
Humidity Range Storage	5 – 90% (non-condensing)
